Tanaka THT-2000 Illustrated Parts Manual

www.tanakapowerequipment.com
PARTS INFORMATION
custsvc@nikko-tanaka-usa.com
Page 2
THT-2000
CRANKCASE & FLYWHEEL • FIGURE 2
See Figure 1
ITEM PART NUMBE
R
DESCRIPTION QTY COMMENTS
2-21 0720650090 CRANKCASE ASS'Y 1 Includes bearings, seals and gasket
2-22 09006500200 GASKET,CRANKCASE 1
2-23 99966122240 SEAL,OIL,#12227 2
2-24 99961600115 BEARING,BALL,6001 C3 2
2-25 33000200210 SHIM,12.2X19X.10 V Shims are as needed
2-25 33000200220 SHIM,12.2X19X.15 V
2-25 33000200230 SHIM,12.2X19X.20 V
2-25 33000200240 SHIM,12.2X19X.30 V
2-26 59900601200 CUSHION 1
2-30 99461050304 BOLT,HEX,5X30S 3
2-31 1552154980 ROTOR,MAGNETO 1
2-34 99101080011 NUT,8 1
2-35 10002100200 BOLT,STUD,6X22 2
