Tanda AQUATOP - Dividing Wall Without SS Frame: Anchoring Cases

MAN-AT-O3-1 Manual Aquatop (2019) 4
Dividing wall without SS frame : anchoring cases
With SCUBA-plates:
• Fix both anchoring cases to the SCUBA-plates for dividing panel®, on the prepared
places (slots).
• Hang the collar of the panels over the anchoring cases with fixing ribs, so that they
cling.
• The panel should be mounted symmetrically to limit the gap between the panel and the
side walls of the pool. Width of the gap/side ≤ 8mm.
• Turn the locking pin 90° to anchor the panel behind the lower stainless steel part.
