LCD MONITOR User s Manual
15
LCD MONITOR User s Manual
16
Adjust COLOR at User Mode in OSD Color
Temp Menu.
Color is irregular.
Check the power connection.
(Refer to page 5)
Power LED is dark.
No picture.
Power LED is Red
Check the signal cable or signal Source.
(Refer to page 5)
Screen is not clear.
Check the resolution and frequency of
computer and video card, and set up
again.Refer to the current monitor
mode and standard signal mode table.
(Refer to page 12)
Display is unstable and
trembling.
Remove and check attaches to the signal line
(Video extension cable and others)
and switch on.
Troubleshooting
Type a-si TFT Active matrix
Screen Size 106.7cm (Diagonal)
Maximum Resolution
1366 X 768@ 60 Hz
Pixel Range
0.681(H) mm X 0.227(V) mm
Display Colors 16.7M (RGB 8-bit data)
Contrast Ratio 1000 : 1
Viewing Angle 89° / 89° / 89° / 89°
Response Time 10 msec
Luminance 500 cd/m
Horizontal Frequency 91kHz (Max.)
Vertical Frequency 85Hz (Max.)
Maximum 300W
standby Mode Under 20W
SOURCE, -,+,
Video Analog RGB
DVI Digital
Audio S/PDIF (Coaxial)
Video VGA,SVGA,XGA,WXGA
Audio IEC-958 S/PDIF 32kHz,44.1kHz,48kHz,96kHz
Safety Standard UL,C-TICK,EK,CCC
EMI CE,MIC,BSMI,FCC
Size and Weight
1022 615 98 / 29kg
LCD
Panel
Synchro
nization
Model FS-L4201C
Input
Signal
Compati
bility
Power
Consumption
Control key
Rear side
Safety
Standard
& EMI
Dimension
Specification
To Next Page
Loading...
General
