1.4 Metering
The equipment is provided with the following metering ranges using analogue moving coil
meters:
Unit
Metering Ranges
Voltage
Current
Low
High
X1
X10
KV5-100 mk2
3kV
6kV
10mA
100mA
KV3-250 mk2
1.6kV
3.2kV
30mA
300mA
KV5-200 mk2
3kV
5kV
20mA
200mA
The ranges on both instruments are selected by means of switches located on the front panel.
