T&S B-0133 - Part Number Guide

Part Number Guide
3
Body Faucet Assemblies
1 Asm, Faucet (Rigid) 002832-40
2 Faucet Body (Rigid) *
3 Washer 001019-45
4 Asm, Coupling Flange 002893-40
5 Asm, Cartridge
6 LH, w/Spring Checks 002711-40
RH, w/Spring Checks 002712-40
7 Handle, Lever - Hot 001637-45
Handle, Lever - Cold 001636-45
8
Body, Swivel Unit 3/8
Index, Button
‘O’-Ring
Hot (Red) 001661-45
Cold (Blue) 001660-45
9 Screw, Handle 000922-45
16 * Optional Supply Connector Kit B-0230-K
* Order Separately
Pre-Rinse Assembly
10 Asm, Spray Valve B-0107
11 Asm, Flex S/S Hose B-0044-H
12 Spring, Overhead 000888-45
13 Spring, Body 000821-40
14 Nipple, 3/8" x 18" 000369-40
15 Asm, Finger Hook & Screw 002873-40
