Page 14
Rear I/O
The bottom of the chassis features a variety of I/O ports, including USB ports, LAN connector,
HDMI ports and audio jacks on the motherboard. Please refer to the specification in motherboard
manual.
You will find the I/O position as below.
VESA Mount Installation
Please remove the stand before installing VESA bracket.
Attention:
It is recommend to reserve 3 cm space between the VESA bracket and the wall.
