Tangent spectrum X5 BT User Manual

SPECIFICATIONS
AUDIO
R
L
PHONO
GND
PHONO
(For use with a turntable without built-in phono pre-amp):
Slide the Phono / Line switch to phono position.
Connect the RCA L/R from your turntable to the RCA L/R inputs on the rear panel of
the Tangent Spectrum X6 BT.
Connect the ground wire from the turntable to the GND on the rear panel of the
Tangent Spectrum X6 BT.
Press AUX 1 on the Tangent Spectrum X6 BT remote.
Speaker Type/Crossover:
Tweeter/Midrange/Woofer:
Amplifier power:
Sensitivity:
Frequency response:
Amplifier type/AC Power:
Input Connections:
Cabinet finish:
Cabinet(WxDxH)mm:
Net weight (Kg):
Powered Speaker
1” / 2x5”
2x60W
90dB
50Hz-20kHz
Class-D / AC100-240V/50-60Hz
Bluetooth/jack 3.5/Line RCA/Optical/Coaxial/Phono
Black matt or White matt painting
166 x268 x 923mm
13,5 kg / unit
CONNECT A TURNTABLE

Tangent spectrum X5 BT Specifications

General

Brand	Tangent
Model	spectrum X5 BT
Category	Speakers
Language	English
