Kit A - CMS 50 3/CVS 4
Adapter Ring Adapter Plate
R2.0
ø224.9
ø188±0.3
R2.0
R2.0
2.2
AA
11.0
1.0
170.0° 22.0
4.0
ø365±0.3
ø195.0
ø285.8
ø300.0
ø4.5
Kit B - CMS 603 /CVS 6
Adapter Ring
Clamp Extension Moulding
ø365±0.5
A
A
ø292.9
ø253±0.5
R2.0
R2.0
R2.0
2.2
11.0
1.0
4.0
10.0°
22.0
SPLIT LINE
15.0
ELLIPSE
25.0
ELLIPSE
8.0
AA
2.0
10.020.0
8.1
2.0
Clamp Extension Moulding
SPLIT LINE
15.0
ELLIPSE
25.0
ELLIPSE
8.0
AA
2.0
10.020.0
8.1
2.0
14 15Quick Start GuideCMS 3.0 & CVS SERIES
