010_ MERCURY 7 MANUAL
SET-UP DIAGRAMS
Fig.1 7.4 Plinth Assembly
Fig.3 Connection 7.4, Single Wire Mode
POWER AMPLIFIER
--+
L
+
R
SPEAKER
TO RIGHT
Fig. 2 Connection 7.1, 7.2 and 7C
POWER AMPLIFIER
--+
L
+
R
SPEAKER
TO RIGHT
LINKS IN PLACE
HF+HF-
LF+LF-
