16 Revolution XT Quick Start Guide 17
Other important information
1. Register online. Please register your new
MUSIC Group equipment right after you purchase it by
visiting tannoy.com. Registering your purchase using our
simple online form helps us to process your repair claims
more quickly and e ciently. Also, read the terms and
conditions of our warranty, if applicable.
2. Malfunction. Should your MUSIC Group
Authorized Reseller not be located in your vicinity,
you may contact the MUSIC Group Authorized Ful ller for
your country listed under “Support” at tannoy.com. Should
your country not be listed, please check if your problem
can be dealt with by our “Online Support” which may also
be found under “Support” at tannoy.com. Alternatively,
please submit an online warranty claim at behringer.com
BEFORE returning the product.
3. Power Connections. Before plugging the
unit into a power socket, please make sure you are using
the correct mains voltage for your particular model.
Faulty fuses must be replaced with fuses of the same type
and rating without exception.
Important information
REVOLUTION XT 6 REVOLUTION XT 6F REVOLUTION XT 8F REVOLUTION XT Mini REVOLUTION XT C
Performance
Recommended amplifier power
(watt RMS)
25 - 120 25 - 150 25 - 200 25 - 100 25 - 120
Continuous power handling
(watt RMS)
60 75 100 50 60
Peak power handling (watt) 240 300 400 200 240
Sensitivity (2.83 volt @ 1 m) 89 dB 90 dB 91 dB 88 dB 89 dB
Nominal impedance (ohm) 8 8 8 8 8
Frequency response (-6 dB) 46 Hz - 32 kHz 38 Hz - 32 kHz 34 Hz - 32 kHz 68 Hz - 52 kHz 62 Hz - 52 kHz
Drive Units
Dual Concentric high frequency
25 mm (1") Linear PEI dome
with Torus Ogive WaveGuide
and Omnimagnet technology
25 mm (1") Linear PEI dome
with Torus Ogive WaveGuide
and Omnimagnet technology
25 mm (1") Linear PEI dome
with Torus Ogive WaveGuide
and Omnimagnet technology
20 mm (0.79") Linear PEI dome
with Torus Ogive WaveGuide
and Omnimagnet technology
20 mm (0.79") Linear PEI dome
with Torus Ogive WaveGuide
and Omnimagnet technology
Dual Concentric low frequency
150 mm (6") multi-fibre paper
44 mm (1.75") voice coil
150 mm (6") multi-fibre paper
44 mm (1.75") voice coil
200 mm (8") multi-fibre paper
44 mm (1.75") voice coil
100 mm (4") multi-fibre paper
32 mm (1.26") voice coil
100 mm (4") multi-fibre paper
32 mm (1.26") voice coil
Bass driver —
150 mm (6") multi-fibre paper
pulp cone with rubber surround.
44 mm (1.75") edge wound
voice coil
200 mm (8") multi-fibre paper
pulp cone with rubber surround.
44 mm (1.75") edge wound
voice coil
—
2 x 100 mm (4") multi-fibre
paperpulp cone with rubber
surround.35 mm (1.38") edge
wound voice coil
Crossover
Crossover frequency 1.8 kHz 250 Hz & 1.8 kHz 250 Hz & 1.8 kHz 2.8 kHz 2.8 kHz
Crossover type
Passive low loss 2nd order
low pass, 1st order high pass
Passive low loss 2nd order
low pass, 1st order high pass
Passive low loss 2nd order
low pass, 1st order high pass
Passive low loss 2nd order
low pass, 1st order high pass
Passive low loss 2nd order
low pass, 1st order high pass
Construction
Enclosure type Downward ported reflex
Downward ported twin
cavity coupled reflex
Downward ported twin
cavity coupled reflex
Rear ported reflex Rear ported reflex
Volume 10.8 l (0.38 cu. ft.) 30.7 l (1.08 cu. ft.) 48.8 l (1.72 cu. ft.) 3.4 l (0.12 cu. ft.) 7.6 l (0.27 cu. ft.)
Dimensions (H x W x D)
(incl. plinth)
400.5 x 221 x 302 mm
(15.8 x 8.7 x 11.9")
1005 x 269 x 317 mm
(39.6 x 10.6 x 12.5")
1080 x 317 x 345 mm
(42.5 x 12.5 x 13.6")
272.2 x 152 x 199.3 mm
(10.7 x 6.0 x 7.8")
176.9 x 450 x 205.6 mm
(7.0 x 17.7 x 8.2")
Net weight 8 kg (17.6 lbs) 17 kg (37.5 lbs) 21.7 kg (47.8 lbs) 3.5 kg (7.7 lbs) 8 kg (17.6 lbs)
Finish Dark Walnut Medium Oak Dark Walnut Medium Oak Dark Walnut Medium Oak Dark Walnut Medium Oak Dark Walnut Medium Oak
Technical Specifications
