3.
Tool-free Assembly
2.1.
Connect the front and rear base parts
by pushing the plastic pegs on one
half into the corresponding slots on
the other half.
Loosen the red lock nut on the extension
column in anticlockwise direction.
1
2
1
2
3
4
Run the power cord orderly through the column, the base and the red lock nut.
Screw the column on the main body, then the base on the column
(make sure the base slot towards the rear side).
To adjust the height of tower fan, take out or assemble with the column for your
preference.
Screw up the red lock nut to lock up.
Buckle the power cord into the 3 holes of the base slot, for making sure the base is
upright on the level ground.
1
2
3
4
06
Tower Fan
07
Tower Fan
4.
(Optional Assembly)
Tower fan without extension column Tower fan with extension column
Rear
Front
36"
42"
To Next Page
