Tar River BDR-165 - Page 35

35
Drum Mower BDR-135,165, 185
Central Frame BDR-135, 165, 185
Item
Part # Description Qty.
1 DM20175-35
Central beam BDR-135
1
DM20175-65 Central beam BDR-165 1
DM20175-85 Central beam BDR-185 1
2 DM150205 Rear plate cover 1
3 LW12 Washer lock M12 Galv. 2
4 BM1212530 Bolt HH M12-1.25 x 30 8.8 2
5 LNM1015 Nut self-locking M10-1.5; BDR-185 5
LNM1015 Nut self-locking M10-1.5; BDR-135, BDR-165 4
6 FW10 Washer flat M10; BDR-185 3
FW10 Washer flat M10; BDR-135, BDR-165 2
7 BM101540 Bolt HH M10-1.5 x 40 8.8 Galv.; BDR-185 only 1
8 FW16 Washer flat M16 Galv.; BDR-185 2
FW16 Washer flat M16 Galv.; BDR-135, BDR-165 1
9 LNM1620 Nut self-locking M16-2.0; BDR-185 only 1
10 DM20760 Stand 1
11
DM11024 Large Spring R-clip
1
12
DM10057 Spacer Washer- M40
2-3 (as req’d.)
13 DM21903 PTO Safety Guard 1
14 DM20131 Angular Axis 1
15 DM20389 Axis joint bushing 2
16 DM20391-35 Clevis; BDR-135, BDR-185 1
DM20391-65 Clevis; BDR-165 1
17 DMSWM2017 Washer, special bendable M20 1
18 TNM2015 Nut low profile M20-1.5 1
19 BM1217590 Bolt HH M12-1.75 x 90 8.8 Galv. 1
20 FW12 Washer flat M12 1
21 LNM12175 Nut self-locking M12-1.75 Galv. 1
22 CP5x40 Pin cotter M5 x 40 Galv. 2
23 SPA2832 SPA 2832 v-belt; BDR-135 3
SPA2932 SPA 2932 v-belt; BDR-165 4
SPA3150 SPA 3150 v-belt; BDR-185 4
24 DMT0215 External v-belt guard; BDR-135 1
DMT20157 External v-belt guard; BDR-165 1
DMT20251 External v-belt guard; BDR-185 1
24a DMT0211 Internal v-belt guard; BDR-135 1
DMT20144 Internal v-belt guard; BDR-165 1
DMT20162 Internal v-belt guard; BDR-185 1
25 DMT20246 V-belt tensioner 1
26 SPN16x40 Mower pin M16 Galv. 1
