Tar River BDR-165 - Page 53

53
Drum Mower BDR-135,165, 185
Complete Drum Unit - Drum BDR-135, 165, 185
Item
Part # Description Qty.
DMSC3535
Drum spindle complete; BDR-135
1
DMSC3565
Drum spindle complete; BDR-165
1
DMSC0085
Drum spindle complete; BDR-185
1
1 SRE-25 Snap ring eternal M25 3
2 DM82005 Spacer washer M25 (0.3, 0.5 or 1mm as required) -
3 DM10019-65 Small bevel gear Z16; BDR-135, BDR-165 1
DM10019-85 Small bevel gear Z17; BDR-185 1
4 OS406210 Oil seal 40 x 62 x 10 1
5 B6305ZZ Bearing 6305 ZZ 1
6 DM150088 Spacer washer M50 x 62 (0.3, 0.5 or 1mm as required) -
7 OR70x4 Sealing ring M70 x 4 1
8 DM10747 Drum hub 1
9 DM10031 Sealant 1
10
SRI-90 Snap ring internal M90
1
11 B6210 Bearing 6210 1
12 B62092RS Bearing 6209 RS 1
13 DM10790 Working disc hub 1
14 B6210RS Bearing 6210 RS 2
15 KM080732 Key M8 x 7 x 2 1
16 DM10617 Reducing gear drive shaft 1
17 KM080780 Key M8 x 7 x 80 1
18 DM82005 Spacer ring 25 (0.3, 0.5 or 1mm as required) -
