Instructions to connect the mower to the tractor:
1. Insert the bottom push rods of the tractor (Drawing #4, point 1) in the suspension frame pins (first
the left one, then the right one) and secure them with cotter pins (Drawing # 4, point 3).
2. Slide the end of the upper connector between the yoke plates using the holes, then connect it with a bolt and
se- cure it with a cotter pin.
3. Lift the mower to relieve the support (Drawing # 4, point 5
4. Lift the support and support it with a cotter pin.
5. Tighten the chain (Drawing # 4, point 4) that is limiting the side tilting of the tractor’s suspension system.
Assembly of the PTO Shaft
The drum mower should be equipped with an efficient PTO shaft with a guard, safety sign or the CE marking as well as the tech-
nical specifications in accordance with the technical guidelines.
Using a PTO shaft with parameters different than those recommended by the manufacturer of the machine may over- load the shaft,
damage it or result in pulling both parts apart while lifting the machine and so create hazard for the operators and the environment.
While assembling the PTO shaft, you should make sure, that the external pipe of the cover is on the side of the trac- tor.
Tractor Mower
Instructions to install the shaft:
• Lower the mower down to the ground, turn off the engine and take out the key from the ignition.
• Insert the female tube end yoke to the power input of the machine and the power take-off of the tractor and secure it
from sliding out with rivets.
• Check whether the rivets secure the ends of the shaft from sliding out during operation.
• Install the chains of the shaft cover; one to the cover of the tractor’s power take-off, and the other to the cover of the
machine’s power input.
WARNING using a damaged PTO shaft, without the cover or a damaged cover, and without the additional cover on the
