Drum Mower BDR-135,165, 185
Cutting Unit - Main Frame BDR-135, 165
Item
Part # Description Qty.
1 DM10192-135
Main frame BDR-135
1
DM10192-165 Main frame BDR-165 1
2 FW10 Washer flat M10 (BDR-135) 20
FW10 Washer flat M10 (BDR-165) 24
3 LNM1015 Nut self-locking M10-1.5 (BDR-135) 22
LNM1015 Nut self-locking M10-1.5 (BDR-165) 26
4 DM150012 Washer sealing 8
5 BM1217530 Bolt HH M10-1.75 x 35 8.8 (galv.) 12
6 LW10 Washer lock M10 16
7 DM10187 Large bearing housing 1
8 DM10190 Small bearing housing 1
9 B6205 Bearing 6205 1
10 B6305 Bearing 6305 1
11
-
12
DM10047-35 Frame shaft BDR-135
1
DM10047-65 Frame shaft BDR-165
1
13
SRI-62 Snap ring internal M62
2
14 DM82005 Shim M25 (4, 0.3;0.5 or 1MM as required) -
15 KM080736 Key M8 x 7 x 36 1
16 KM080750 Key M8 x 7 x 50 4
17 DM10090-65 Large gear Z21 3
18 -
19 DM85023 Spring pin M6 x 16 4
20 BM101560 Bolt HH M10-1.5 x 60 8.8 Galv. Half Thread 4
21 DM10019-65 Small gear wheel Z16 1.65m 1
22 DM10276 Attachment hub 1
23 DM10263 Attachment shaft 1
24 B6305ZZ Bearing 6305 ZZ 1
25 DM10136-135 Cover BDR-135 1
DM10136-165 Cover BDR-165 1
26 B30305 Bearing 30305A 1
27 OS255210 Seal M25 x 52 x 10 1
28 SRE-25 Snap ring external M25 1
29 LW12 Washer lock M12 Galv. 4
30 BM1212530 Bolt HH M12-1.25 x 30 8.8 Galv. 4
