Drum Mower BDR-135,165, 185
Cutting Unit - Main Frame 185
Item
Part # Description Qty.
1 DM10192-185
Main frame BDR-185
1
2 FW10 Washer flat M10 24
3 LNM1015 Nut self-locking M10-1.5 30
4 DM150012 Sealing washer 4
5 BM1217530 Bolt HH M10-1.75 x 35 8.8 (galv.) 12
6 LW10 Washer lock M10 20
7 DM10150 Large bearing housing 1
8 DM10175 Small bearing housing 1
9 B6305 Bearing 6305 3
10 -
11
-
12
DM10047-85 Frame shaft BDR-185
1
13
SRI-62 Snap ring internal M62
2
14 DM82005 Shim M25 (4, 0.3;0.5 or 1MM as required) -
15 KM080736 Key M8 x 7 x 36 1
16 KM080750 Key M8 x 7 x 50 4
17 DM10090-85 Large gear Z21 3
18 DMT7040 Spacer sleeve for Frame Shaft 1
19 DM85023 Spring pin M6 x 16 4
20 BM101560 Bolt HH M10-1.5 x 60 8.8 Galv. half thread 8
21 DM10019-85 Small gear wheel Z16 1.85m 1
22 DM10276 Attachment hub 1
23 DM10263 Attachment shaft 1
24 B6305ZZ Bearing 6305 ZZ 1
25 DM10136-185 Cover BDR-185 1
26 B30305 Bearing 30305A 1
27 OS255210 Seal M25 x 52 x 10 1
28 SRE-25 Snap ring external M25 1
29 LW12 Washer lock M12 Galv. 4
30 BM1212530 Bolt HH M12-1.25 x 30 8.8 Galv. 4
31 DM10250-85 Small pulley 1
32 DM10088 Tab washer 4
33 BM101525 Bolt M10-1.5 x 25 8.8 Galv. 24
34 DM10441 Vent/Fill plug 1
35 DM10177 Support bushing BDR-185 2
36 DM10180 End plate 1
To Next Page
