56
Drum Mower BDR-135,165, 185
Guard Assembly - Drum BDR-135, 165, 185
Item
Part # Description Qty.
DM30015-185
Metal guard set (includes items 1-6); BDR-185
1
DM30015-165
Metal guard set (includes items 1-6); BDR-165
1
DM30015-135
Metal guard set (includes items 1-6); BDR-135
1
1 DM30016R Right shield 1
2 DM30069 Middle shield 1
3 DM30016L Left shield 1
4 DM30043 Bent reinforcement bar; BDR-185 2
DMT0804 Bent reinforcement bar; BDR-135, BDR-165 2
5 DM30071 Reinforcing angle bar; BDR-185 1
DM30237 Reinforcing angle bar; BDR-165 1
DMT0805 Reinforcing angle bar; BDR-135 1
6 DM30145-85 Reinforced apron; BDR-185 1
DM30145-65 Reinforced apron; BDR-165 1
DM30145-35 Reinforced apron; BDR-135 1
7
BM101525 Bolt HH M10-1.5 x 25 8.8 Galv.
19
8 FW10 Washer flat M10 38
9 LNM1015 Nut self-locking M10-1.5 19
10 BM061016 Bolt HH M6-1.0 x 16 8.8 Galv. 37
11 NM1015 Nut HH M10-1.5 37
12 LFW10 Flat washer large M6 37
13 LFW10 Flat washer large M6 37
14 BM0812516 Bolt HH M8-1.25 x 16 8.8 Galv. 4
15 LW08 Washer lock M8 8
16 NM08125 Nut HH M8-1.25 4
Note: Part #6 (Apron) is one piece on the current models. We use the suffix M=Male snaps & F=Female
snaps for the two piece aprons until our stock is expended.
