23
Sub-Compact Rotary Tiller DLT & DLT-S Series
Item
Part # Description Qty.
BM101530 Bolt- M10 x 1.5 x 30
NM1015 Nut- M10 x 1.5
DP1003 A-Frame
LW10 Lock Washer– M10
DP1005 Lower Suspension Pin
DP2006 Input shaft
B32010 Bearing- 32010
DP2008 Gasket- Rear Cover
DP2009 Rear Cover- Gearbox
10 BM1012525 Bolt- M10 x 1.25 x 25
11 LW10 Lock Washer- M10
12 BM061525 Bolt- M12 X 1.5 X 25
13 DP2013 Hex coupler
14 KM120830 Key- M12 x 8 x 30
15 OS559012 Oil Seal- M55 x 90 x 12
16 DP2016 Gearbox Housing
17 SRE-32 Snap Ring- External- M32
18 DP2018 Bevel Gear
19 B6207 Bearing- 6207
20 OS456512 Oil Seal- M45 x 65 x 12
21 DP2021 Gasket
22 BM1012525 Bolt- M10 x 1.25 x 25
23 SRE-90 Snap Ring- External- M90
24 DP2025 Bushing– Gearbox
25 DP2026 Gearbox Plug
26 SRI-72 Snap Ring- Internal- M72
27 DP2027 Shield- Right
28 DP2028 Shield- Left inner
29 DP2029 Shield- Left Outer
30 DP2030-42 Tail Gate- (DLT-S42)
30 DP2030-50 Tail Gate- (DLT-S50)
31 DP2031-42 Hex Shaft- (DLT-S42)
31 DP2031-50 Hex Shaft- (DLT-S50)
32 B30207 Bearing- 30207
33 DP1033 Tailgate Rod- (DLT-S42)
33 DP10331 Tailgate Rod- (DLT-S50)
34 DP1034 Sprocket Upper
35 SW24 Stop Washer
36 DP1036 Drive Chain- 12A
DLT-S Series Rotary Tiller
