DRL-048, DRL-072 Crop Seeder
Hopper Assembly
Item
Part # Description Qty.
1 DL1003-55 Hopper box complete; DRL-048 1
DL1003-78 Hopper box complete; DRL-072 1
2 DL1001-55 Hopper lid; DRL-048 1
DL1001-78 Hopper lid; DRL-072 1
3 DL5003 Lid piston 2
4 DL7001-L Seed cup distribution box, large seed -
DL7001-S Seed cup distribution box, small seed -
5 DL3002 Fertilizer/seed tube - 533mm length (front seed cups) -
DL3001 Fertilizer/seed tube - 470mm length (rear seed cups) -
6 DL10005 Right chain cover 1
7 DL10004 Left chain cover 1
8 DL3004A Chain, right side 8B - 108 links 1
9 DL3004B Chain, left side 10B - 109 links 1
10 DL1005 Bearing, assembly drive shaft 4
11 B305222 Bearing; B305222 2
12 DL7000-48 Hex seed box shaft; DRL-048 1
DL7000-72 Hex seed box shaft; DRL-072 1
13 BM061012 Bolt M6x1.0x12 -
14 DL2003 Drive sprocket Z40 1
15 DL2006 Drive sprocket Z26 1
16 DL7004A Rate adjustment face plate (front) 1
DL7004B Rate adjustment face plate (rear) 1
17 DL7005 Counter pointer 2
18 LNM0610 Lock nut M6x1.0 -
19 DL1006 Cleanout spout 2
20 DL7002 Clamp assembly with hardware 84
21 BM061016 Bolt M6x1.0x16 -
22 BM0812535 Bolt M8x1.25x35 4
23 DL7006 Seed cup funnel 14-20
24 SA2005 Handle assembly 2
25 SA2005K Locking knob 2
26 SA9005 Tube wire clamps 20
27 BM0812540 Bolt M8x1.25x40 2
28 DL3005A Right side lower sprocket 8B 12T 1
29 CP3x70 Cotter pin - M3x70 (Distribution box) 14-20
30 DL7007 Waste/Seed/Fertilizer Shut Off Flap 14-20
31 DL7009 Spinner handle w/bolt and nut 2
32 DL5005B Left side lower sprocket 10B 11T 1
33 SA4012 Seed box shaft, spiral spline (front seed box) 10
SA4013 Seed box shaft, straight spline (rear seed box) 10
