DRL-048, DRL-072 Crop Seeder
Hopper Assembly
Item
Part # Qty.
34 SA4014 -
35 SA4015 -
36 SA4021 -
37 SA4019 -
38 CP2.5x20 -
39 SA8009 4
40 2
41 4
42
LNM1420
SA4016
SA4017
2
43 3020238 6
44 LW10 4
45 FW10 4
46 SA4018 8
47 BM1015020 4
48 BM1015015 6
49 BM0812535 4
50 SA4020 2
51 GN0815 2
52 SA4022
Description
Shaft guide, seed cup
Shaft guide retainer, seed cup
Sheet metal screw
Clevis, composite M10x60
Cotter pin M2x22
Plastic washer, adjustment handle
Nut, elastic stop M14-2.00
Chain guard bracket, short (attach chain guard to hopper)
Chain guard bracket, long (attach chain guard to rear frame)
Nut, hex head M10-1.50
Washer, lock M10
Washer, flat M10
Washer, rubber 2mm x 10 mm x 25 mm
Bolt M10-1.50x20
Bolt M10-1.50x15
Bolt M8x1.25x35
Lock collar, handle
Grease nipple M8x1.0
Flap, seed cup
-
