27
ERC Square Back Rotary Cutter
*NOTE: Before ordering parts for the gearbox, SEE Notes on Page 29.
Item
Part # Description Qty.
*25 ERC030421 Gear box (smooth input shaft) 45 hp - 4ft 1
ERC030521 Gear box (smooth input shaft) 45 hp - 5ft/6ft 1
ERC031521 Gear box (6 spline input shaft) 45 hp - 4ft 1
ERC031621 Gear box (6 spline input shaft) 45 hp - 5ft/6ft 1
26 OP1/4-18B Oil breather plug - 1/4 NPTF 1
27 BM162045 Bolt HH M16-2.0x45 4
28 FW16 Washer flat M16 7
29 LW16 Washer lock M16 4
30 NM1620 Nut HH M16-2.0 4
31 BM2430180 Bolt HH M24-3.0x180 1
32 GN081S Grease nipple M08x1.0 straight 2
33 ERC030037 Wheel hub 1
34 CBM1217530 Bolt carriage M12-1.75x30 4
35 FW12 Washer flat M12 4
36 LNM12175 Nut self-locking M12-1.75 4
37 ERC030017 Tail wheel Ø390x95 1
38 ERC670014 Wheel fork 1
39 LNM2430 Nut self-locking M24-3.0 1
40 ERC030419 Tail wheel arm - 4 ft 1
ERC030519 Tail wheel arm - 5 ft 1
ERC030619 Tail wheel arm - 6 ft 1
41 LYNPN08 Lynch pin M08 3
42 ERC030031 Lower hitch pin 2
43 ERC670018 Height adjustment bar 1
44 ERC030420 Rear brace - 4 ft 2
ERC030520 Rear brace - 5 ft 2
ERC030620 Rear brace - 6 ft 2
45 BM1620140 Bolt HH M16-2.0x140 1
46 BM1620160 Bolt HH M16-2.0x160 1
47 ERC030013 Hitch bracket 1
48 ERC030011 Steel sleeve M22.5x16.5 1
49 ERC030030 Upper hitch pin 1
50 RC4 R clip M4 2
51 ERC030035 Steel sleeve M32x16.5 1
52 LW22 Washer lock M22 2
53 NM2225 Nut HH M22-2.5 2
ERC Rotary Cutter Frame
