Targa 19" User Manual

Targa Visionary LCD 19-4 Wide
17
English
Technical Specifications
LCD Display 19.0” Wide TFT (16:10)
Power Management
Energy Star-compliant,
VESA DPMS-compatible = 1 W
Power consumption while operating: max.
45 W
Supported Resolution
max. 1440 x 900
Refresh rate max. 75 Hz
Pixel size 0.285 x 0.285 mm
Display Colours 16.2 million
Viewing angle 160°/160° (CR > 10)
Inclination 0°~20°
Contrast Ratio 800:1 (typical)
Brightness 300 cd/m² (typical)
Response time 5 ms (typical)
Active Screen Area 410 mm x 256 mm
Temperature Operation: 0°C ~ + 35°C
Storage -20°C ~ +60°C
Compliance
TÜV/GS, CE, Energy Star, TCO ’99
ISO 13406-2, 2002/95/EG (RoHS)
Input voltage Input voltage 220-240 VAC, 50 Hz
Speaker 1W x 2
VESA Wall Mount Receptacle 100 x 100 mm
Signal Input 15-pin D-Sub VGA (Analogue)
