ENGLISH
6
Installation of Wall Mount (Optional)
This LCD display supports industry standard wall-mount kit. To wall-mount this
LCD display, you need to purchase a wall-mount kit from your local dealer.
Read the instructions from the wall-mount kit before proceeding as below:
• Lay the LCD display face-down on flat surface covered by a towel or
blankets.
• Remove the two screws.
• Detach the foot-stand from the display module.
• Attach the wall-mount bracket onto the back of the display module by means
of these four VESA holes.
• Follow instructions from the wall-mount kit to attach the wall-mount bracket
to the wall.
Remove the
two screws
Detach the hinge
and the foot-stand
The four
VESA holes
Hinge
Foot-stand
