Target 3-2-1 Cube - Step 8: Final Wall Attachment

16
1. Align center of top panel of unit with wall stud.
2. Place short end of L-bracket against wall/wall stud. Use 1-1/2 in. screw to secure L-bracket to wall.
3. Use 1/2 in. screw to secure L-bracket to top panel.
warning
All units MUST be fastened to the wall.
step 8.
(H6) x 1
L-bracket
(H4) x 1
L-bracket screw
#10 x 1/2 in. athead
(H5) x 1
wall screw
#10 x 1-1/2 in.
wall
stud
top panel
top panel
wall
stud
