Diagram 5 Parts List – Motor Group, 1.5 hp Electric
16August2002
ITEM P/N DESCRIPTION QTY
1 ------ Motor Group 1
2 177789 Motor Base 1
3 177771 Motor, 1.5hp (1750 RPM) 1
4 173014 Washer, Flat M10 4
5 139749 Capscrew, Hex Hd M10 x 1.50 x 25mm 4
6 139748 Locknut, Fiber M10 x 1.50 4
7 020063 Key, Square .188 x 1.50 Lg 1
8 176222 Nut, Jam hex Hd M10 x 1.50 1
9 177884 Capscrew, Hex Hd M10 x 1.50 x 65mm (Full Thread) 1
10 030931 Pulley w/SS, 3V3.00-.875 Bore w/SS(Incl. Item 11) 1
11 020550 Screw, Set Soc Cup Pt .312-18UNC x .375 2
Callout Designation:
On The Diagram.
QTY
The Quantity only at this location.
This the total quantity used
throughout the entire diagram.
