Diagram 6 Parts List – Engine Group, 11 hp Honda
16August2002
ITEM P/N DESCRIPTION QTY
1 ------ Engine Bench Assembly 1
2 177792 Engine Base 1
3 177764 Honda Engine, 11hp Model GXV340 1
4 020763 Washer, Flat .312 SAE 4
5 020785 Lockwasher, Split .312 Dia 2
6 020316 Capscrew, Hex Hd .312-18UNF x 1.00 2
7 020373 Capscrew, Hex Hd .312-18UNC x 1.50 2
8 020197 Locknut, Fiber .3125-18UNC 2
9 177766 Spacer, Engine Clutch 1
10 163130 Key, Square .250 x 3.25 1
11 177765 Clutch 1
12 020744 Washer, Flat .438 Dia 1
13 020787 Lockwasher, Split .438 Dia 1
14 177767 Capscrew, Hex Hd .438-20UNF x 2.75 1
15 177868 Switch Box Weldment 1
16 163688 Capscrew, Hex Hd M6 x 1.0 x 16mm 2
17 139745 Locknut, Fiber M6 x 1.0 2
18 CLIP Included With Honda Engine 1
19 172315 Capscrew, Hex Hd M5 x 0.8 x 16mm 1
20 176222 Nut, Jam hex Hd M10 x 1.50 1
21 177884 Capscrew, Hex Hd M10 x 1.50 x 65mm (Full Thread) 1
22 177860 Fitting Assy, Oil Drain M20 x 1.5 x 3/8 Hose Barb 1
23 177859 Fitting, Connector, M20 Male x 1/2-14NPT Female 1
24 177017 Fitting, 1/2-14NPT x 3/8 Hose Barb 1
25 167305 Hose Assembly, Oil Drain 1
26 020049 Hose Clamp, Worm Drive 1
27 167306 Cap, Blanking 1
28 167622 Tube Nut, M16 1
Callout Designation:
On The Diagram.
QTY
The Quantity only at this location.
This the total quantity used
throughout the entire diagram.
is not
To Next Page
