Target Fairmont - Gazebo Assembly Process; Step 01: Base and Post Leg Assembly

7
step 01:
(Part O)×12
M6*15mm bolt with washer
(Part T)×1
allen wrench
Do not completely tighten screws until all screws are in place.
ATTENTION: To avoid damage to your new gazebo, please
use either the carton or another soft surface such as carpet as a
working surface to prevent product damage during assembly.
1. Attach the U-shaped part 1 (G) to the post leg (A), secure with M6*15mm bolt with washer (O) using the allen wrench (T).
2. Insert the post base (I) into the post leg (A), secure with M6*15mm bolt with washer (O) using the allen wrench (T).
1.
2.
A
A
A
I
I
O
O
O
G
3.
G
3. Repeat above steps until 4 U-shaped part 1 (G) and post base (I) are secured to the post leg (A).
