Target Fairmont - Step 02: Beam Attachment to Post Legs

8
step 02:
(Part O)×16
M6*15mm bolt with washer
Do not completely tighten screws until all screws are in place.
(Part T)×1
allen wrench
1. Attach the beam (B) to the post leg (A), secure with M6*15mm bolt with washer (O) using allen wrench (T).
2. Repeat above step until the 4 beam (B) are secured to the post leg (A).
A
A
A
A
A
B
B
B
B
B
O
