Tarmo TAR010 - Page 102

Part # Description Qty Part # Description Qty
30 Flat Washer Ø8 1 109 Bush 1
52 Handle Bush 1 110 Tie Plate A 1
70
External Teeth Lock Washer
Ø6
1 111 Tie Bar 1
71 Lock Nut Nylon M6 2 112 Tie Bar A 1
78 Spring Washer Ø6 2 113 Bolt 1
96 Split Washer Ø6-E 1 114 Handle Assy. 1
105 Tie Bar 1 115
Wave Single Coil Spring Lock
Washers Ø10
1
106 Adjusting Hook Assy. 1 116
Hexagonal Socket Head Cap
Screw M6x8
3
107 Tie Plate 1 117 Tiller Grip 1
108 Adjusting Bolt 1
BRAKE HANDLE ASSY.
