Tarmo TAR010 - Page 101

Part # Description Qty Part # Description Qty
1
Hex Bolt M8
x25
20 7 Side Flap Support 1
2 Rear Flap Support 1 8 Side Flap 1
3 Rear Flap 1 9 Side A Flap 1
4 Chassis Assy. 1 10 Side A Flap Support 1
5 Spring Washer Ø8 20 11 Side B Flap 1
6 Lock Nut Nylon M8 20 12 Side B Flap Support 1
CHASSIS AND FLAP ASSY.
