26
REASSEMBLING DRIVELINE SHIELD
1. Replace white tabbed collar in groove of PTO shaft.
2. Slide driveline shield tube over white tab collar. Align
slots/holes with holes in tube.
3. Slide universal joint cover up tube toward universal joint.
Align grease fitting on shield with white square tabs on
collars. This will properly align the position notch and all
three (3) tabs.
4. Slide collar shield into place until locked.
SERVICE
