Tarter RC104BL - Parts; Parts List

33
PARTS
Item # Part # Description
1 RCTA
Rotary Cutter Tire/Wheel & Fork
Assembly
2 2000029 Rotary Cutter Gearbox w/ Castle
Nut & Cotter Pin
3 RCS45A 4' PTO Shaft w/ hardware
3 9000372 5' PTO Shaft w/ hardware
3 RCS6A 6' PTO Shaft w/ Hardware
4 C1L Category 1 Lift Pin
5 RCBH Rotary Cutter Blade Holder
6 RCBBWW Blade Bolt Set (2pk)
7 RCBL4 4' Rotary Cutter Blades (2pk)
7 RCBL5 5' Rotary Cutter Blades (2pk)
7 RCBL6 6' Rotary Cutter Blades (2pk)
8 9000187 4' Rotary Cutter A-Frame Assy
(black)
8a 9000188 5' & 6' Rotary Cutter A-Frame
Assy (black)
9 9000189 RBRC402 Back Brace (2pk)
(black)
9a 9000190 RBRC502 Back Brace (2pk)
(black)
9b 9000191 RBRC602 Back Brace (2pk)
(black)
10 9000192 4' Pivot Plate (2pk) (black)
10a 9000193 5'&6' Pivot Plate (2pk) (black)
11 9000194 New Style 4' Lift Arms (2pk)
(black)
11a 9000195
New Style 5' & 6' Lift Arms (2pk)
(black)
12 9000196 Rotary Cutter A-Frame Height
Adjuster (black)
13 LTWWB Laminated Tire & Wheel w/ Bolts
14 RCWF RC Wheel Fork
15 FHBWN Fork & Hub Bolt w/ Nut
16 114W 1-1/4" Flat Washer
17 RCGBH Rotary Cutter Gearbox Hardware
(4pk)
18 NSRCBSH New Style RC Backstrap Hard-
ware (4pk)
19 RCAFHAH RC A-Frame Height Adjuster
Hardware (4pk)
20 RCPPH Rotary Cutter Pivot Plate Hard-
ware (2pk)
21 RBRC56MHWH RBRC manual Holder w/ Hard-
ware
22 HUB Wheel Hub for Tarter/TSC Rotary
Cutters
23 WFBWN Wheel Fork Bolt w/ Nut
Parts Overall View
RC104BL, RC205BL, RC206BL
Not
Shown
9000197 Inner Pivot Plate Bushing (2pk)
(black)
Not
Shown
9000198 Outer Pivot Plate Bushing (2pk)
(black)
Not
Shown
PTOBWS Shear Pin PTO Shaft Hardware Kit
Not
Shown
SR Tarter/TSC Rotary Cutter Snap
Ring (3pk)
Not
Shown
GZ Grease Zerk (5pk)
Not
Shown
PTOGZ PTO Shaft Grease Zerk w/ 45
degree bend
Not
Shown
9000199 4' Pin Bushing (2pk) (black)
Not
Shown
9000200 5' & 6' Pin Bushing (2pk) (black)
Not
Shown
9000148 RBRC402 Front Rubber Guard Kit
(Black)
Not
Shown
9000149 RBRC502 Front Rubber Guard Kit
(Black)
Not
Shown
9000150 RBRC602 Front Rubber Guard Kit
(Black)
Not
Shown
9000151 RBRC402 Rear Metal Guard Kit
(Black)
Not
Shown
9000152 RBRC502 Rear Metal Guard Kit
(Black)
Not
Shown
9000153 RBRC602 Rear Metal Guard Kit
(Black)
Not
Shown
9000154 RBRC402 Front Rubber & Rear
Metal Guard Kit (Black)
Not
Shown
9000155 RBRC502 Front Rubber & Rear
Metal Guard Kit (Black)
Not
Shown
9000156 RBRC602 Front Rubber & Rear
Metal Guard Kit (Black)
