Tascam X-9 - Audio Specifications; General Specifications

10 Specifications, etc.
TASCAM X-9 Owner’s Manual 31
Audio specifications
General specifications
Program equalization
HIGH (frequency range)
6 kHz to 20 kHz
gain –40 dB to +12 dB
MID (frequency range)
200Hz to 6kHz
gain –40 dB to +12 dB
LOW (frequency range)
20 Hz to 200 Hz
gain –40 dB to +12 dB
Microphone equalization
HIGH (frequency range)
10 kHz
gain –12 dB to +12 dB
LOW (frequency range)
100 Hz
gain –12 dB to +12 dB
Frequency response
LINE
20 Hz to 20 kHz ±2.0 dB
PHONO
20 Hz to 20 kHz ±2.0 dB
MIC
20 Hz to 20 kHz ±2.0 dB
Signal-to-noise ratio
PGM
84 dB (IHF A weighting)
PHONO
77 dB (IHF A weighting)
MIC
70 dB (IHF A weighting)
Total harmonic distortion
LINE
< 0.025%
PHONO
< 0.035%
MIC
< 0.040%
Crosstalk > 70 dB @ 1 kHz
Samplers (1 and 2) 8 seconds of record/playback per sampler
Effector memories 30 x 8 (types) = 240 memories
EQ memories 100
Voltage requirements USA/Canada 120 VAC, 60 Hz
U.K./Europe 230 VAC, 50 Hz
Australia 240 VAC, 50 Hz
General export 120 VAC, 60 Hz, 230 VAC, 60 Hz
Power consumption 42 W
Applicable electromagnetic environment E4
Peak inrush current 0.9 A
Dimensions (w x d x h) 320 x 354 x 87(mm)
12.6 x 13.9 x 3.4 (in)
Weight 7 kg (15.4 lb.)
Operating temperature 5°C to 35°C (41°F to 95°F)
Supplied accessories Rack-mounting ears
Rack-mounting kit
Fan cover
Eight RCA plug covers
Optional accessories MIDI/Digital Out board
