Task Force 227684 - Page 19

Item N
0
. Part N
0
.
Qty
Description
1 3331237 1 Upper handle
2 3410737 2 Knob
3 3220837 2 Long bolt
4 3331337 1 Lower handle
5 3420237 1 Rear rubber curtain
6 3330737 1 Left handle bracket
7 3310137 1 Deck
8 3330537 1 Height adjustment lever
9 3420137 4 Wheel
10 3290137 6 Hairpin clip
11 3330537 1 Link bar
12 3320137 1 Front wheel shaft assembly
13 3320237 1 Rear wheel shaft assembly
14 3340137 1 Spring
15 3220737 1 Blade nut M10
16 3331035 1 Blade plate
17 3411635 1 Blade locking plate
18 3330137 1 Blade
19 3410237 1 Fan
20 3220137 1 Cross screw
21 3410637 1 Side discharge chute
22 3410537 1 Side discharge cover
23 3320537 1 Side discharge cover shaft
24 3330637 1 Side discharge cover bracket
25 3340237 1 Spring
26 3330737 1 Right height adjustment level
27 3331237 1 Cord path
28 3410403 1 Cord holder
29 3220303 2 Cross screw
30 3610137 1 Motor assembly
31 3411237 1 Grill
32 3410337 1 Motor housing
33 3220337 4 Cross screw
34 3110137 1 Switch assembly
35 3410737 1 Cord restraint
36 3220437 2 Cross screw
37 3490137 1 Foam sleeve
19
