Item Description Qty
1 Left housing support 1
2 Right housing support 1
3 Reel cut 1
4 Top push handle 1
5 Center handle pieces 2
6 Lower handle 2
7 Pin 2
8 Bearing 2
9 Gear wheel 2
10 Housing 1
11 Long shaft 1
12 Cutting bar 1
13 Cutting bar adjustment bolt 2
14 Cutting bar adjustment spring 2
15 Shaft 1
16 Cutting height adjustment 2
17 Rear wheel 2
18 Rubber cover 2
19 Front wheel 2
20 Wheel cover 2
21 Cutting bar adjustment locked nut 2
22 Foam grip 1
23 Knob 8
24 Bolt 8
25 Bolt 2
26 Flat washer 2
27 Bolt 2
28 Rear wheel shaft 2
29 Cutting height adjustment lever 2
30 Nut M8 8
31 Spring washer 6
32 Flat washer 2
33 Spring washer 2
34 Rubber protection cover 2
35 C-clip 2
36 Bolt 2
37 Flat washer 6
38 Flat washer 10
39 Spring washer 2
40 Bolt 2
41 Grass catcher bag 1
PARTS DIAGRAM LIST
