Cutting height adjustments: (Fig. 7)
The cutting height of the mower adjusts from 1-3/4 - 2-3/4 in. by moving the height adj
ustment levers to the required position.
To achieve the lowest cutting position, one at a time, move the the adjustment levers on both
sides, located next to the
smal
ler wheels, up to the highest position.
To achieve the highest cutting position, move the adjustment levers on both sides to their lowe
st position.
Other
cutting heights are achieved by moving the adjustment levers to any stop between the highest and lowest positions.
NO
T
E: The two adjustment levers MUST
be set to the same position (height).
Height adjustment
OPERATION
Fig. 7
