Task Force 26093 - Assembly and Adjustments; Unpacking and Inspection

1
2
3
4
5
8
9
13
6
10
11
12
UNPACKING (Fig. B)
Remove the chipper components from the packaging and examine them carefully.
.
NOTE: Do not discard box or any packing material until all parts are examined.
9
1
Housing with hopper 1 pcs
2 Push Bar 1 pcs
3 Wheel 2 pcs
4 Axle 1 pcs
5 Clip Holder 2 pcs
6 Screw 4 pcs
7 Collecting Bag (not show) 1 pcs
8 L-wrench 1 pcs
9 13mm wrench 1 pcs
10 Wheel Nut 2 pcs
11 Inner Washer 2 pcs
12 Outer Washer 2 pcs
13 Stand Assembly 1 pcs
IF ANY PART OF THE CHIPPER IS MISSING OR
DAMAGED, DO NOT PLUG
THE TOOL IN
UNTIL THE DAMAGED PART IS
REPAIRED OR REPLACED..
Fig. B
WARNING
ASSEMBLY AND ADJUSTMENTS
