Task Force 26133 - Attaching The Handle To The Mower Base

ATTACHING THE HANDLE TO THE MOWER BASE: (Fig.2)
1. Align holes (1) at the lower end of each handle arm with short posts (2) extending from
the
mower base side plates. Slide lower ends of handle arms onto posts.
5
Fig. 2
1
2
2. After handle arm holes are on posts, use pliers to snap C-clips (1) onto the slotted (2)
posts on both sides to secure handle.
