Structural layout
1 Cover (removable)
2 Float body and draw lock button
3 Strainer
4 Recovery tank
5 Locking button for suction hose
6 Suction hose connection
7 Castor wheel
8 Pump rocking switch
9 Vacuum rocking switch
10 Spray hose connection
11 Fresh water tank filter
12 Locking button for recovery tank
13 Unlocking button for cover
14 Fresh water tank
15 Motor housing
1
13
3
14
15
4
5 7 8
9
11
12
10
6
2
