Taski aquamat 20 - Malfunctions; Technical Information

40
Malfunctions
Technical information
Malfunction Possible causes Troubleshooting Page
Machine without function
Machine is switched off
• Switch on the main switch
37
No power supply
• Insert the power supply plug into
the mains socket
Main cord defect • Replace the main cord
Motor does not turn • Contact your service partner
No suction or weak suction
Main switch is switched off • Switch on the main switch 37
Motor fault • Contact your service partner
Dirt in the squeegee • Remove the dirt
Cover not correctly put on • Position the cover
Gasket faulty or not available • Replace the gasket if necessary
Suction hose broken or fitting loose
• Replace suction hose or tighten fit-
ting
Recovery tank full/float has triggered
• Turn off the suction motor, empty
and clean tank
Drainage opening/filter blocked
• Empty the tank then clean the
drainage opening/filter
37
Little or no water
Pump switched off • Switch pump on
Spray nozzles blocked • Remove and clean spray nozzles
Spray nozzles removed • Attach or replace spray nozzles
Fresh water filter blocked
• Empty fresh water tank and clean
filter
39
Machine aquamat 20
Working width 24 24 cm
Rated voltage 230-240V~ 100-120V~ AC
Frequency 50 60 Hz
Rated power, nominal 900 900 W
Dimensions (LxWxH) 80x38x72 80x38x72 cm
Main cord length 15 15 m
Maximum weight of operational machine 25 25 kg
Tank capacity +/- 5% 22 22 l
Values according to IEC 60335-2-68
Sound pressure level LpA 70 dB(A)
Uncertainty KpA 2.5 dB(A)
Vibration <2.5 m/s2
Uncertainty K 0.25 m/s2
Splash water guard IPX4
Protection class II
