10
Transport
The control of drive and the speed can be controlled on the machine handle and the
speed control. The speed is stepless variable.
Fill the tank
t Turn the machine on (main switch).
The indicators light up.
By lightly pressing the speed control in the direction of
drive, the machine is set in motion. Letting the speed
control go stops the machine.
t Turn off the machine (main switch).
t Open the machine hood.
This symbol indicates the solution tank.
t Remove the tank cover closing.
t Open the tank cover/dosing cup.
Caution:
Maximum permissible water temperature 60 °C/140 F.
t Fill water into the solution tank.
The check mark indicates the max. fill level (page 7).
Caution:
The solution should contain no solvents, chlorine, hydrochloric acid or
hydrofluoric acid, since these would damage or destroy the machine.
max.60˚C
max.140˚F
