6
Overview
1 Probe (dirty water tank full)
2 Nozzle-/ tube holder
3 Option: Recycling filter
4 Soiled solution tube
5 Flexible suction hose
6 Tank cover
7 Squeegee
8 Suction filter
9 Recovery tank
10 Rear steering drivewheel
11 Fresh water tank (diaphragm sack)
with dosing cup
12 Disconnector charger jack
13 Brush unit
14 Impact protection
15 Parking brake
16 Drive pedal
17 Brake pedal
18 Forwards / Backwards lever and
horn
19 Keyswitch
20 Control panel
21 Steering wheel
22 Drivers seat adjustment
23 Driver seat with safety switch
24 Battery cover (main fuse and battery
plug)
25 Tank hood
26 Suction filter
1
2
3
6
7
4
15
16
17
5
18
19
20
8 9 10 11 12 13 14
2122
23242526
