Taurus 3D Smith Machine - Parts List

1 reinforcing plate 2
2 L shape base frame 2
3 hexagon bolt M10*120 8
4 washer Φ10 38
5 lock nut M10 18
6 slide rod 2
7 fix plate right 1
8 rubber cushion Φ60*Φ30*30 4
9 connection tube 4
10 fix plate left 1
11 allen bolt M10 4
12 stand tube 2
13 out hexagon bolt M10*75 8
14 rubber pad 4
15 out hexagon bolt M10*70 2
16 guide rod 2
17 safety hook right 1
18 safety hook left 1
19 hexagon socket screw without head M8 4
20 barbell rod 1
21 sliding sleeve 2
22 barbell plate holder 2
23 washer φ12 2
24 spring gasket φ12 2
25 hexagon socket screw M12*40 2
26 chip up bar 1
27 out hexagon bolt M10*65 2
28 butterfly clip 2
29 L shape connect plate 2
30 simit column 28
31 simit nut 28
27
7.2 Parts List
No. Name Specication Qty.
