Single Pulley
Step 3
L NOTICE
Before installing the front covers, Make sure that the bolt hole faces in the direction of the main
frame like in the footate below. (also applies to step 11).
1. Fasten the pulley housings (13) to the cable height adjuster (7) with two bolts (31), four washers
(41) and two nuts (45).
2. Attach the two front covers (5) to the main frame (1) with eight bolts (39).
