Single Pulley
2.3.2 Assembly (right)
Step 7
1. Remove the upright frame (2) along with the cable height adjuster (7) from the main frame (1)
by loosening the two bolts (33), four washers (42) and two nuts (46).
2. Loosen the two bolts (34) and two nuts (46) from the main frame (1).
3. Remove the pulley (18) from the guide rod retainer (8) by loosening the two screws (40), the bolt
(34) and the nut (46).
4. Remove the guide rod retainer (8) and the two guide rods (4) from the main frame (1) by
loosening the two screws (35).
5. Turn the guide rod retainer (8) around and reattach it along with the guide rods (4) to the main
frame (1) with the previously removed screws.
6. Re-attach the pulley (18) to the guide rod retainer (8) with the screws and nuts removed
previously.
L NOTICE
Please refer to step 15 and follow the fth instruction to reinstall the cable (26) if the cable needs to
be adjusted.
