28
Single Pulley
Step 12
L NOTICE
The pulleys (18) are xed simiultaneously with the cable (26)
1. Remove one pulley (18) from each of the pulley housings (13) by loosening two bolts (34) and
two nuts (46).
2. Guide the ball end of the cable (26) through the left pulley housing (13) and re-fasten the
previously removed pulley (18) with a bolt (34) and a nut (46).
3. Pass the ball end of the cable (26) through the right pulley housing (13) and re-fasten the
previously removed pulley (18) with a bolt (34) and nut (46).
