Taylor Made Convertible Bimini Top Assembly and Instruction Guide:
This Kit contains the following components: If you are missing any of the listed
parts please contact Customer Service at (800)-628-5188 before proceeding
with the installation.
(1) Sewn Tops and storage boot
(2) Hardware bag that includes:
a. (12) #8 x 5/8” SS sheet metal screws
b. (8) #10 x 1” SS sheet metal screws
c. (2) Universal deck mounts
d. (2) SS eye straps
e. (20) SS windshield clips
f. (2) Webbing Tie-down Straps with SS dog snaps
(3) Aluminum Frame Components:
a. Two-Bow Frame
i. (2) A- Bow Assemblies with attached Jaw-slides (longest) Left/ Right
ii. (2) B- Bows (second longest)
iii. (2) Center Bows
b. Three-Bow Frame
i. (2) A- Bow Assemblies with attached Jaw-slides (longest) Left/Right
ii. (2) B- Bows (second longest)
iii. (3) Center Bows
iv. (2) C-Bows (shortest)
Important Notice – This top is for installation on
aluminum V hull shing boats with walk-thru
windshields only. It includes 7/8” Windshield clips –
if your windshield frame is a different size or design,
you’ll need to purchase the correct size clips before
assembly and installation.
Tools required: Phillips head screw driver, Drill and 5/32” bit and tape
measure.Before you begin, you’ll need a clean at workplace and the job is
best done with a helper.
