Digital Inputs and Outputs
Connector (S/PDIF, AES3-id compatible):
Formats (S/PDIF and TOSLINK):
Connector (ADAT® or TOSLINK):
Format (ADAT®):
Digital IO Engine:
Clock and Jitter
Internal Sample Rate (fallback):
External Sample Rates:
Jitter Rejection Engine:
Jitter Rejection Filter (4th order):
DIO Interface Jitter:
DA Conversion Jitter:
Output Phase (all digital outputs):
Processing Delay DIO @ 96/48 kHz:
Frequency Response DIO:
Line Output Channel 1/2
Connectors:
Impedance:
Max. Output Level:
Digital Gain:
THD:
Dynamic Range incl. DIM:
Freq. Response:
Crosstalk:
TECHNICAL SPECIFICATIONS
RCA Phono, BNC adapter included,
75 Ohm, 1 Vpp (terminated)
S/PDIF (24-bit), IEC 958, Pro-status bits
Optical Pipe
Ch. 1 to 4 @ 48 kHz, Ch. 1 to 4 SMUX @ 96 kHz
TCAT DICE JR, handling all IO formats
48 kHz
43 to 97 kHz, jitter rejection at all rates
JET™ technology in TCAT DICE JR
> 3 dB @ 10 Hz, > 100 dB @ 600 Hz
< 1 ns peak, BW: 700 Hz to 100 kHz
< 42 ps RMS, BW: 100 Hz to 40 kHz
< 0.5% of Sample Period
0.15/0.3 ms
DC to 23.9 kHz ± 0.01 dB @ 48 kHz
XLR balanced with ground sensing
< 100 Ohm
+13 dBu, -5 dBu DIM activated
Off to +12 dB
< -93 dB (0.002 %) @ 1 kHz, -1 dBFS, 0 dB gain
> 118 dB (121 dB a-weighted), 20 Hz to 20 kHz
+0/-0.2 dB, 20 Hz to 20 kHz
< -98 dB, 20 Hz to 20 kHz
