6
OVERVIEW – REAR PANEL
Phones
1/4" jack connection for headphones.
Power In
Use the supplied 12V DC
power supply.
Analog Outputs
Balanced analog outputs for
active monitors, amplifier or mixer.
TOS & ADAT
Lightpipe inputs and outputs on standard TOSLINK connectors
(TOS: Channels 1-2 – ADAT: Channels 1-4).
SPDIF I/O
24 Bit SPDIF/AES3-id input and output on
RCA connectors.
