Item No. Description Quantity Req. Designator Remarks

18-CB0122-JNX RES. C.F. 1.2k OHM 1/6W +/-5% 1 R946

40-2918T6-MAE1X P.C.B. MAIN CTL BD 1

41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J042

41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J043

41-WJ0110-B00 WIRE BARE JUMPER 11MM 1 J044

41-WJ0090-B00 WIRE BARE JUMPER 9MM 1 J309

41-WJ0080-B00 WIRE BARE JUMPER 8 MM 1 J917

41-WJ0130-B00 WIRE BARE JUMPER 13MM 1 J918

41-WJ0085-B00 WIRE BARE JUMPER 8.5MM 1 D261

41-WJ0050-B00 WIRE BARE JUMPER 5MM 1 L301

18-DD0333-FNX RES. M.F 33K OHM 1/4W +/-1% 1 R303

25-BDB479-M1X CAP. ELEC 4.7 UF 25V +/-20% 1 C223

25-BFB470-M1X CAP. ELEC 47 UF 50V +/-20% 1 C250

41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 J039A

41-WJ0065-B00 WIRE BARE JUMPER 6.5MM 1 R226

41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J312

11-630MFP-0AX TRANSISTOR IRF630MFP 1 Q414

18-CB0822-JNX RES. C.F. 8.2K OHM 1/6W +/-5% 1 R420

41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J916

08-0029S6-PWY ASS'Y - POWER PARTS 1

10-0001H8-FBX DIODE 1H8 (FAST RECOVERY) 1 D851

10-00RU4C-F0X FAST RECOVERY DIODE RU4C 1 D831

10-0EU2YX-FBX DIODE EU2YX (FAST RECOVERY) 1 D832

10-0RU4YX-F0X DIODE RU4YX (FAST RECOVERY) 1 D833

10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D807

10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D808

10-CW574C-DJX DIODE CW574CD 1 D824

11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q803

11-C144ES-0BX TRANSISTOR PDTC144ES (NPN) 1 Q804

11-P08P06-0AX TRANSISTOR SPP08P06P 1 Q802

11-SK3451-0CX TRANSISTOR 2SK3451-01MR 1 Q801

13-DA1684-62P IC TDA16846-2(Q67040-S4494) 1 IC801

13-L7805C-VAP IC L7805CV 1.5A (REGULATOR) 1 IC805

13-L7809C-VAP IC L7809CV 1 IC804

13-LM431A-CZT IC LM431ACZ(TO-92) 1 IC803
